LTP3A Automatic Tissue Processor Linear Type

$0.00

SKU: LTP3A Category: Automatic Tissue Processor

Capacity of Single Cup: 1000ml
Temperature Control Precision: ±1℃
Frequency of Agitation: 2 times/minute
Working Voltage: AC 220V±10% 50Hz (standard model)

Description

Description

LTP3A Automatic Tissue Processor Linear Type

Features:

1. Fully intelligent design, enabling timely automatic determination and recovery from an abnormal event
2. High-quality blue-colored LCD screen operated with two optional programs offers a clear and reliable display
3. Manual adjustment can be conducted anytime during the programmed automatic operation; afterwards, the system automatically enters the programmed operation
4. Green inner-cycling air purification system to efficiently adsorb, and remove, poisonous gas
5. Imported high-quality parts, smooth operation, low noise, ergonomic design
6. Approximately 60 tissue samples can be processed at the same time

Technical Data
Number of Cups	12 (nine cups for reagents and three cups for paraffin)
Capacity of Each Cup	1000 ml
Length of Processing Time	Adjustable within 0-99 hours for the 1st station and within 0-24 hours for other stations
Heating Mechanism	Internal dry heating automatically begins when the tissue enters the 2nd cup, thus avoiding unnecessary energy waste
Temperature Range of Paraffin Cup	adjustable within RT – 99°; dual protection
Temperature Control Precision	±1℃
Frequency of Agitation	2 times/minute
Dripping Time	Adjustable within 10-60 s; shake/drip above cup
Acceptable Temperature Range of Operation Environment	0 ~ 40℃
Tissue Protection Cup	at the 7th station
Working Voltage	AC 220V±10% 50Hz (standard model); AC110V±10% 60Hz
Power	500 W
Heating Control	heating automatically begins when the tissue enters the 2nd cup, thus avoiding unnecessary energy waste
Dimensions	1010×420×450 mm (W×D×H)
Weight	67 kg
Battery backup	with more than 6 hours of continual running power
